首頁 >> 突波保護器突波吸收器
上頁 突波保護器突波吸收器
圖片 文件名稱產品說明
SPD for wind turbines type SPD for wind turbines type
JDA-太陽能突波保護(吸收)器簡錄 JDA-太陽能突波保護(吸收)器簡錄
TvssPro® E-系列電源防雷箱 120至600V, 電源防雷箱, 最大洩流量50至1200KA, 符合UL1449與 CSA C22.2#8 防水防塵等級 NEMA4X, IP64
JDA-太陽能突波保護(吸收)器
SPD型錄

突波保護器(或稱突波吸收器)型錄
PV20/24-MV-R PV20/24-MV-R
PV20/xx-MVCR Type 2 surge arrester designed for low voltage DC system against surges at the boundaries from lightning protection zone 0B-2and higher. ◎ In accordance with IEC61643-11 and UL1449-4th ◎ DC SPD for common mode protection ◎ Pluggable module design, easy replacement ◎ High discharge current 20kA 8/20 ◎ Reliable supervision due to disconnection device; ◎ Fault indication by red indication flag in window; ◎ With remote alarm terminal optional;
PV40/125-2V-R 突波保護器(或稱突波吸收器)應用於獨立系統直流低電壓突波吸收器,最大放電電流40KA 170Vdc,附輔助電驛輸出。
PV20/48-MVCR 組合波8/20us, In/Imax. 10/20KA,最大連續使用電壓(DC)56Vdc, 額定電壓48Vdc,電壓保護水平280V, 阻燃UL94-V0, 溫域-40~+80℃
PV40/(48-100)-MVCR PV40/(48-100)-MVCR
JDA-太陽能突波吸收器
PV40/100-MVCR

突波保護器(或稱突波吸收器)應用於獨立系統直流低電壓突波吸收器,
最大放電電流40KA 100Vdc,附輔助電驛輸出。

PV40/150-MVCR type II的避雷器,低電壓直流系統設計,針對0B-2浪湧避雷區與較高的邊界。
PV40/600-MVCR (上方進線) 突波保護器(或稱突波吸收器)應用於太陽能光伏發電系統突波保護,最大放電電流40KA 600Vdc,附輔助電驛輸出,上方進線。
PV40/600-MVCR (下方進線) 突波保護器(或稱突波吸收器)應用於太陽能光伏發電系統突波保護,最大放電電流40KA 600Vdc,附輔助電驛輸出,下方進線。
PV40/1000-MVCR type II的SPD設計,適用於低壓系統,免受於1-2避雷區與較高的邊界的電湧突波。
PV50/600-MVCR 突波保護器(或稱突波吸收器)應用於太陽能光伏發電系統突波保護,最大放電電流40KA 600Vdc,附輔助電驛輸出
PV60/600-MVCR 突波保護器(或稱突波吸收器)應用於太陽能光伏發電系統突波保護,最大放電電流60KA 600Vdc,附輔助電驛輸出。
PV15/1200-MVCDR 組合波8/20us, In/Imax. 7/15KA,最大連續使用電壓(DC)1220VDC, 額定電壓1200VDC, 阻燃UL94-V0, 溫域-40~+80℃
PV25/600-MVCDR 組合波8/20us,最大連續使用電壓(DC)615VDC, 額定電壓600VDC, 阻燃UL94-V0, 溫域-40~+80℃
PV40/1000-MVCDR 突波保護器(或稱突波吸收器)組合波8/20us, In/Imax. 20/40KA, 阻燃UL94-V0, 溫域-40~+80℃
PV40/1500-MVCDR 突波保護器(或稱突波吸收器)組合波1500Vdc, 8/20us, In/Imax. 20/40KA, 阻燃UL94-V0, 溫域-40~+80℃
PV50/(600-1200)-MVCDR PV50/(600-1200)-MVCDR
PV50/1000-MVCDR 組合波8/20us, In/Imax. 20/50KA,最大連續使用電壓(DC)1120Vdc, 阻燃UL94-V0, 溫域-40~+80℃
PV50/1000-MVCDR-act 組合波8/20us, In/Imax. 20/50KA,最大連續使用電壓(DC)1120Vdc, 阻燃UL94-V0, 溫域-40~+80℃
PV50/1200-MVCDR 組合波8/20us, In/Imax. 20/40KA,最大連續使用電壓(DC)1240VDC, 額定電壓1200VDC,電壓保護水平4.8KV, 阻燃UL94-V0, 溫域-40~+80℃
PV80/1000-MVCDR 突波保護器(或稱突波吸收器)組合波8/20us, In/Imax. 40/80KA, 溫域-40~+80℃
PV100/1000-MVCDR 突波保護器(或稱突波吸收器)組合波8/20us, In/Imax. 50/100KA, 溫域-40~+80℃
PV**/1500-MVCDR 突波保護器(或稱突波吸收器)應用於太陽能光伏發電系統突波保護,最大放電電流60KA/100Ka,1500/1520Vdc,附輔助電驛輸出。
D1-40/***-2MV-R D1-40/***-2MV-R
D1-40/275-2MV-R 突波保護器(或稱突波吸收器)組合波8/20us, In/Imax. 20/40KA, 阻燃UL94-V0, 溫域-40~+80℃
D1-50/275-2MV-R 突波保護器(或稱突波吸收器)組合波8/20us, In/Imax. 20/50KA, 阻燃UL94-V0, 溫域-40~+80℃
D1-200/320-2MV-R 組合波8/20us, In/Imax. 100/200KA,, 阻燃UL94-V0, 溫域-40~+80℃
D1-100/***-2MVGT-R D1-100/***-2MVGT-R
D3-50/420-3MV-R type I型的突波保護,低壓供電系統設計,免受於1-2避雷區與較高的邊界的電湧突波。
D3-40/440-3MV-R 組合波8/20us, In/Imax. 5/10KA,最大連續使用電壓(DC)DC 8, 額定電壓DC5,電阻燃UL94-V0, 溫域-25~+70℃
D3-40/680-3MV-R 突波保護器(或稱突波吸收器)組合波8/20us, In/Imax. 20/40KA, 阻燃UL94-V0, 溫域-40~+80℃
D3-40/680-3MV-R-act 組合波8/20us, In/Imax. 20/40KA,最大連續使用電壓(DC)680/900Vdc, 阻燃UL94-V0, 溫域-40~+80℃
D3-50/320-3MV-R 組合波8/20us, In/Imax. 20/50KA,最大連續使用電壓(AC/DC)320/420, 阻燃UL94-V0, 溫域-40~+80℃
D3-30/380-4MV-R 額定電壓380V/220V(L-L/L-N),電壓保護水平平@在1.8KV @3KA 1.3KV , 阻燃UL94-V0, 溫域-40~+80℃
D3-80/385-4MV(-R) 組合波8/20us, In/Imax. 40/80KA,最大連續使用電壓(AC/DC)385/505, 溫域-40~+80℃
D3-40/320-4MV-R 突波保護器(或稱突波吸收器)組合波8/20us, In/Imax. 20/40KA, 阻燃UL94-V0, 溫域-40~+80℃
D3-40/440-4MV-R 突波保護器(或稱突波吸收器)組合波8/20us, In/Imax. 20/40KA, 阻燃UL94-V0, 溫域-40~+80℃
D3-60/440-4MV-R D3-60/440-4MV-R
D3-100/320-4MV-R 突波保護器(或稱突波吸收器)組合波8/20us, In/Imax. 200/400KA, 阻燃UL94-V0, 溫域-40~+80℃
D3-160/420-4MV-R D3-160/420-4MV-R
D1-20/275-VG-R 突波保護器(或稱突波吸收器)組合波8/20us, In/Imax. 10/20KA, 阻燃UL94-V0, 溫域-40~+80℃
D1-50/150-VG-R 突波保護器(或稱突波吸收器)組合波8/20us, In/Imax. 25/50KA, 阻燃UL94-V0, 溫域-40~+80℃
D1-80/***-VG-R 組合波8/20us, In/Imax. 40/80KA,, 阻燃UL94-V0, 溫域-40~+80℃
D1-100/***-2VG-R D1-100/***-2VG-R
D3-30/440-3VG-R 突波保護器(或稱突波吸收器)應用於太陽能光伏發電系統,最大放電電流30KA 440Vdc,附輔助電驛輸出。
D3-40/385-3VG-R 2型的SPD設計,適用於低壓系統,免受於1-2避雷區與較高的邊界的電湧突波。
D3-50/320-3VG-R 組合波8/20us, In/Imax.IEC61643-11:2011 20/40KA:UL1449 3rd 20/50KA,最大連續使用電壓(AC/DC)320/420,阻燃UL94-V0, 溫域-40~+80℃
D3-50/420-3VG-R 突波保護器(或稱突波吸收器)組合波8/20us, In/Imax. 20/50KA, 阻燃UL94-V0, 溫域-40~+80℃
D3-65/440-3VG-R 突波保護器(或稱突波吸收器)組合波8/20us, In/Imax. 30/65KA, 阻燃UL94-V0, 溫域-40~+80℃
D3-80/***-3VG-R 組合波8/20us, In/Imax. 40/80KA,, 阻燃UL94-V0, 溫域-40~+80℃
JDA-電力突波吸收器
D3-80/440-3VG-R

突波保護器(或稱突波吸收器)組合波8/20us, In/Imax. 40/80KA, 阻燃UL94-V0, 溫域-40~+80℃
D3-150/385-3VG-R 突波保護器(或稱突波吸收器)組合波8/20us, In/Imax. 75/150KA, 溫域-40~+80℃
D3-100/385-4MVGT-R D3-100/385-4MVGT-R
RLMV20/150 組合波8/20us, In/Imax. 10/20KA,最大連續使用電壓(DC)200VDC, 額定電壓20VDC,電壓保護水平250V, 阻燃UL94-V0, 溫域-40~+80℃
MV80P/320-R MV80P/320-R
JDA-太陽能突波保護(吸收)器
MTMV-xxx


DN-xxx-MB/G2 JDA DN-xxx-MB/G2 data network arrester applied in protection for 2 single wires of balanced interfaces with measuring and controlling system, providing coarse and fine protection, suitable for use in category location B, C (ANSI/IEEE C62.41) or directly at the upstream near the protected devices. Technical Features ◎ Data network protector in according with UL497b,IEC61643-21:2012; ◎ Compact size of 6.2mm to safe much installation space ◎ 35mm Din-rail mounting design; ◎ Limit the transients with gas discharge tubes and transzorb diodes; ◎ Three-stage protection circuit. ◎ Universal one pair data/communication lines protection
DN-xxx-MB/G4 JDA DN-xxx-MB/G4 MODBUS RS485 Data network arrester provide protection for four single lines or two-pair lines in the high-frequency bus systems or video transmissions, suitable for use in category location B, C (ANSI/IEEE C62.41) or directly at the upstream near the protected devices. Technical Features ◎ Data network protector in according with UL497b, IEC61643-:21:2012; ◎ Compact size of 7 mm to safe much installation space ◎ 35mm Din-rail mounting design; ◎ Limit the transients with gas discharge tubes and transzorb diodes; ◎ Two-stage protection circuit. ◎ 4-lines or twp-pair lines protection
DRF25-175-25A-3MV-C(-R) Surge protective device especially for low-voltage power supply system surge protection at the boundaries from lightning protection zone 2-3 and higher. ◎ Multi-stage protection circuit with LC Filter design to protect sensitive electronics. ◎ Provides extensive high frequency & RF filtering ◎ Application for 120~127Vac,220~277Vac(L-N) TT, TN or any 1-phase system with a grounded neutral ◎ Protection capability 25kA 8/20 us ◎ Built in backup fuse for fault current protection ◎ All mode protection ◎ LED failure indication ◎ Remote alarm function available
DN-24/BNC-50 DN-24/BNC-XX surge arrester is designed for coaxial systems protection against the damaging from surges and spikes caused by lightning and other electrical sources, suitable for use in category location B, C (ANSI/IEEE C62.41) or directly at the upstream near the protected devices. Technical Features ◎Data network protector in according with UL497b,IEC61643-21:2012; ◎High discharge capability, total nominal discharge current up to 20kA 8/20; ◎Two-stage protection circuit; ◎Limit the transient with gas discharge tubes and transzorb diodes; ◎Low insertion loss;
DN-24/BNC-75 JDA DN-24/BNC-75 surge arrester is designed for coaxial systems protection against the damaging from surges and spikes caused by lightning and other electrical sources, suitable for use in category location B, C (ANSI/IEEE C62.41) or directly at the upstream near the protected devices. Technical Features ◎ Data network protector in according with UL497b,IEC61643-21:2012; ◎ High discharge capability, total nominal discharge current up to 20kA 8/20; ◎ Two-stage protection circuit; ◎ Limit the transient with gas discharge tubes and transzorb diodes; ◎ Low insertion loss;
DN-24-G(25KA) 插拔模塊,DIN rail安裝,組合波8/20us, In 5KA,溫域-40~+80℃,阻燃UL94-V0
DN-24/RS485 JDA電力突波吸收器(或稱突波吸收器)組合波8/20us, 10/20KA, 溫域-40~+70℃
JDA-訊號突波保護器
DN-24/0420-2G

插拔模塊,DIN rail安裝,組合波8/20us, In/Imax. 5/10KA,
箝制電壓(保護水平)25V,-95V
溫域-40~+80℃,阻燃UL94-V0

DN-48-RJ45-CAT6-HS(POE) This Cat6-PoE Protector is designed for protecting Gigabit Ethernet terminals such as Internet camera, IP Telephone sets, and wireless access point, suitable for use in category location B, C (ANSI/IEEE C62.41) or directly at the upstream near the protected devices. Technical Features ◎ Data network protector In according with standard IEEE802.3at/af,UL497b,IEC61643-21 ◎ PoE compatible, Ethernet CAT6 system protection ◎ High discharge capability, total nominal discharge current 10kA 8/20 and Lightning current up to 1.0KA ◎ In aluminum housing ◎ RJ45 connector for cat6 network technology, 100BaseT, 1000BaseT/1000BaseTx, 8 wires protection
JDA-訊號突波保護器
DN-&&/xxxxx/G

插拔模塊,DIN rail安裝,組合波8/20us, In/Imax. 5/10KA,溫域-40~+70℃
JDA-訊號突波保護器
DN-05RS485-2G-B

訊號用突波消除器DN-&&/xxxxx-2G-B xxxxx:RS232,RS422,RS423,RS485,0/4-20mA,0-5V,0-10V
A. 型式:配電盤內儀表24V 0/4~20mA S232,RS422,RS423,RS485,0-5V,0-10V,訊號使用,Din rail標準固定安裝。
B. 耐突波電流(8/20μs 波形)容量: 10KA In,20KA Im。
C. 限制電壓(突波消除能力):在Cat.B(@3KA)測試條件下≦75V, 8/20us impulse-5KA 35V。

JDA-訊號突波保護器
DN-&&/xxxxx-2G

訊號用突波消除器DN-&&/xxxxx-2G xxxxx:RS232,RS422,RS423,RS485,0/4-20mA,0-5V,0-10V
A. 型式:配電盤內儀表24V 0/4~20mA S232,RS422,RS423,RS485,0-5V,0-10V,訊號使用,Din rail標準固定安裝。
B. 耐突波電流(8/20μs 波形)容量: 10KA In,20KA Im。
C. 限制電壓(突波消除能力):在Cat.B(@3KA)測試條件下≦75V, 8/20us impulse-5KA 35V。

 太陽能路燈專用 RL-2VG-xxx-6-L 太陽能路燈專用
電源防雷器 SDT-110-20-F1 1、二端口F型突波保護器
2、按照IEC61643-11.ANSI/IEEE C62.41-1991標準設計
3、110V單相系統保護
4、35mmDIN導軌安裝
5、LED燈失效指示
6、限制電壓(突波消除能力):保護電壓為110V時,≦[800]V。
7、負載電流=5A

信號突波保護器 SSP-24 1、突波保護器,適用於2對線保護線
2、用於防雷分區0B—2或後續分區
3、低電壓保護水平
4、直流供電電源保護
5、35mmDIN導軌安裝
6、限制電壓(突波消除能力):在Cat.B(@3KA)測試條件下≦75V
7、符合IEC61643-21.ANSI/IEEE C62.41-1991標準

乙太網路RJ45突波保護器  乙太網路RJ45突波保護器
乙太網路RJ45突波保護器 /ITB-05-RJ45H-24P 乙太網路RJ45突波保護器
訊號雷擊計數器ECL-A-9 感應:>100A,LED指示燈,霍爾感測,DIN rail安裝,計數0~99,電池:7.2V,可充電電池,DIN43880, 2module寬36mm,溫域-20~+60℃,阻燃UL94-V0
訊號雷擊計數器ECL-A-24 感應:>100A,LED指示燈,霍爾感測,DIN rail安裝,計數0~99,電池壽命1年,電池:7.2V,可充電電池,DIN43880, 2module寬36mm,溫域-40~+80℃,阻燃UL94-V0
交流突波吸收器 Type :ESF&&-x/***-##A-$$,Enclosure type Surge power Filter,Max. surge current (Available from 25KA ~200KA),power system (Single phase/three phase),Input voltage – Uc(180/320/420/550),Current rating - continuous (5A/10A/16A/20A/32A/50A/63A/100A/ 120A… ),3P/PN/3PN: protection mode(L-N,L-PE,N-PE 3MOV/L-N,N-PE 1MOV+1GDT/L-N,N-PE 3MOV+1GDT),{Applications:Secondauy power circuits/Sub-boards,Computer Systems / Medical Systems,Telecommunication Systems / Recti_ers,All sensitive Electronic Equipment,Process and Control Systems}
餅乾型突波(方型) LKD34S142K 餅乾型突波(方型) LKD34S142K
餅乾型突波(圓型) JDA-32SERIES 餅乾型突波(圓型) JDA-32SERIES
餅乾型突波(圓型針腳) JDA-25JD142K 餅乾型突波(圓型針腳) JDA-25JD142K
