ホーム >> サージ防護・吸収装置
上ページ
サージ防護・吸収装置
型録
取得安全規格一覧
写真
ファイル名
製品説明
JDA サージ保護/吸收デバイスカタログ
JDA サージ保護/吸收デバイスカタログ
TvssPro® Eシリーズ 電源雷サージ保護箱
20-600V, 電源雷サージ保護箱, 最大電流50-1200KA, UL1449 & CSA C22.2#8 防水防塵レベル:NAMA4X, IP64
JDA サージ保護/吸收デバイスカタログ
JDA サージ保護/吸收デバイスカタログ カタログ)
SURGE ARRESTERS FOR LED STREET LIGHT RL-3MVGT/390-10/S LED路燈用SPD
SURGE ARRESTERS FOR LED STREET LIGHT RL-3MVGT/390-10/S LED路燈用SPD
JDA RL(3MV+G)-320-10S,LED路燈用突波保護器
JDA RL(3MV+G)-320-10S,LED路燈用突波保護器
RJ45 CAT6 SURGE PROTECTOR EN-05RJ45HSCAT6
RJ45 CAT6 SURGE PROTECTOR EN-05RJ45HSCAT6
CL12T-VL05BNC-PL220T/3F
サージ防護・吸収装置, Integrated protection for power lines, control lines and video signal lines of the camera
8*MV50/320
8*MV50/320
PVB12.5/1500-MVCDR
サージ防護・吸収装置 PVB12.5/1500-MVCDR
PV サージ吸收デバイス PV15/1200-MVCDR
サージ耐量8/20us, in/Imax 7/15KA, 最大連続使用電圧(DC)1200VDC 定格電圧 1200VDC, 難燃性UL94-V0 温度:-40~+80℃
PV サージ吸收デバイス PV20/24-MV-R
サージ耐量8/20us, In/Imax 10/20KA 最大連続使用電圧(DC)30VDC 定格電圧24VDC, 電圧保護レベル250V, 難燃性UL94-V0, 温度:-40~+80℃
PV20-xx-MVCR
Type 2 surge arrester designed for low voltage DC system against surges at the boundaries from lightning protection zone 0B-2and higher. ◎ In accordance with IEC61643-11 and UL1449-4th ◎ DC SPD for common mode protection ◎ Pluggable module design, easy replacement ◎ High discharge current 20kA 8/20 ◎ Reliable supervision due to disconnection device; ◎ Fault indication by red indication flag in window; ◎ With remote alarm terminal optional;
PV25/600-MVCDR
サージ耐量8/20us 最大連続使用電圧(DC)615VDC, 定格電圧600VDC, 難燃性UL94-V0, 温度:-40~+80℃
PV40/(48-100)-MVCR
PV40/(48-100)-MVCR
In accordance with EN50539, IEC61643-11 and UL1449-4th
DC SPD for common mode protection
Pluggable module design, easy replacement
High discharge current 40kA 8/20
Reliable supervision due to disconnection device
Fault indication by red indication flag in window
With remote alarm terminal optional
JDA PV サージ吸收デバイス PV40/100-MVCR
サージ保護デバイス(或いは吸收デバイス)、 独立システム用の直流低電圧サージ吸收デバイス 最大放電電流40KA 100Vdc 補助リレーア付け
JDA PVサージ吸收デバイス PV40/125-2V-R
サージ保護デバイス(或いは吸收デバイス)、 独立システム用の直流低電圧サージ吸收デバイス 最大放電電流40KA 100Vdc 補助リレーア付け
PV40/150-MVCR
Type 2 surge arrester designed for low voltage DC system against surges at the boundaries from lightning protection zone 0B-2and higher
JDA PVサージ吸收デバイス PV40/600-MVCR 上から配線
サージ保護デバイス(或いは吸收デバイス)はPV 発電システム保護用で 最大放電電流40KA 600Vdc, 補助リレーア付け
PV40/1000-MVC (White Enclosure)
PV40/1000-MVC (White Enclosure)
PV40/1000-MVCR (ホワイトケース)
PV40/1000-MVCR (ホワイトケース)
PV40/1000-MVCR (黒ケース)
PV40/1000-MVCR (黒ケース)
PV40/1000-MVCR (赤/黒ケース)
PV40/1000-MVCR (赤/黒ケース)
PV40-1000-MVCD-R
サージ防護・吸収装置 PV40-1000-MVCD-R
PV40/1500-MVCDR
For solar PV generation system, max.discharge current 40KA, 1500Vdc with aux. relay output.
JDA PVサージ吸收デバイスPV50/600-MVCR
サージ保護デバイス(或いは吸收デバイス)はPV 発電システム保護用で 最大放電電流40KA 600Vdc, 補助リレーア付け
PV50/1000-MVCDR
サージ保護デバイス(或いは吸收デバイス) PV発電システム保護用,最大放電電流40KA 1000Vdc, 補助リレーア付け、上から配線
PV サージ吸收デバイスPV50/1200-MVCDR
サージ耐量8/20us In/Imax 20/40KA 最大連続使用電圧(DC)1240VDC 定格電圧1200VDC, 電圧保護レベル4.8KV 難燃性UL94-V0, 温度:-40~+80℃
PV50/(600-1200)-MVCDR
PV50/(600-1200)-MVCDR
PV60/1500-MVCDR
サージ防護・吸収装置 PV60/1500-MVCDR
JDA PVサージ吸收デバイス PV60/600-MVCR
サージ保護デバイス(或いは吸收デバイス)はPV 発電システム保護用で 最大放電電流60KA 600Vdc, 補助リレーア付け
PV**/1500-MVCDR
8/20us, In/Imax. 30/60KA Max. continuous operating voltage (Vdc):1500/1520 Operating temperature range:-40~+80℃
JDA電力サージ吸收デバイス D1-20/275-VG-R
サージ保護デバイス(或いは吸收デバイス) サージ耐量8/20us In/Imax 10/20KA 難燃性UL94-V0, 温度:-40~+80℃
D1-50/150-VG-R
サージ保護デバイス(或いは吸收デバイス) サージ耐量8/20us In/Imax 25/50KA 難燃性UL94-V0, 温度:-40~+80℃
JDA電力サージ吸收デバイス D1-40/275-2MV-R
サージ保護デバイス(或いは吸收デバイス) サージ耐量8/20us In/Imax 20/40KA 難燃性UL94-V0, 温度:-40~+80℃
JDA電力サージ吸收デバイス D1-50/275-2MV-R
サージ保護デバイス(或いは吸收デバイス) サージ耐量8/20us In/Imax 20/50KA 難燃性UL94-V0, 温度:-40~+80℃
JDA電力サージ吸收デバイス D1-200/320-2MV-R
サージ耐量8/20us In/Imax 100/200KA 難燃性UL94-V0, 温度:-40~+80℃
D3-50(150550)3MV-R
サージ保護, AC Surge protector, D3-50/275-3MV-R, type 1, SCCR) 200kA , UL1449-4th
D3-50-(150-550)-4MV-R
Surge protector, D3-50-550-4MV-R,
D3-50-550-4MV-R
サージ防護・吸収装置 D3-50-550-4MV-R
D3-50-420-4MV-R
サージ防護・吸収装置 D3-50-420-4MV-R
D3-50/320-3MV-R
サージ耐量8/20us In/Imax 5/10KA 最大連続使用電圧(AC/DC)320/420 難燃性UL94-V0, 温度:-40~+80℃
JDA 電力サージ吸收デバイス D3-30/380-4MV-R
定格電圧380V/220V(L-L/L-N)、 電圧保護レベル@ 1.8KV @3KA 1.3KV ,難燃性UL94-V0, 温度:-40~+80℃
JDA電力サージ吸收デバイス D3-40-440-3MV-R
サージ耐量8/20us In/Imax 5/10KA 最大連続使用電圧(DC)DC 8 定格電圧1200VDC ,難燃性UL94-V0, 温度:-25~+70℃
JDA電力サージ吸收デバイス D3-40/440-4MV-R
定格電圧440V/220V(L-L/L-N)、 電圧保護レベル@ 1.8KV @3KA 1.3KV ,難燃性UL94-V0, 温度:-40~+80℃
D3-60/440-4MV-R
D3-60/440-4MV-R
JDA 電力サージ吸收デバイス D3-100/320-4MV-R
サージ保護デバイス(或いは吸收デバイス) サージ耐量8/20us In/Imax 200/400KA 難燃性UL94-V0, 温度:-40~+80℃
D3-160/420-4MV-R
D3-160/420-4MV-R
D3-50-(150-550)-3VG-R
Class I+II (B+C) arrester in accordance with UL1449-4th,
Max. continuous operating voltage MCOV L-N (VAC/DC) 550/710, Enclosure material,extinguishing degree UL94 V-0, Operating temperature range, - 40ºC ~ + 80ºC,
D3-50/320-3VG-R
サージ耐量8/20us In/Imax IEC61643-11:20 11 20/40KA:UL1449 3rd 20/50KA 最大連続使用電圧(AC/DC)320/420
JDA電力サージ吸收デバイス D3-65/440-3VG-R
サージ保護デバイス(或いは吸收デバイス) サージ耐量8/20us In/Imax 30/65KA 難燃性UL94-V0, 温度:-40~+80℃
JDA電力サージ吸收デバイス D3-30/440-3VG-R
ージ保護デバイス(或いは吸收デバイス) PV 発電システム保護用,最大放電電流30KA 440Vdc, 補助リレーア付け
JDA 電力サージ吸收デバイス D3-80/440-3VG-R
サージ保護デバイス(或いは吸收デバイス) サージ耐量8/20us In/Imax 40/80KA 難燃性UL94-V0, 温度:-40~+80℃
JDA 電力サージ吸收デバイス D3-150/385-3VG-R
サージ保護デバイス(或いは吸收デバイス) サージ耐量8/20us In/Imax 75/150KA , 温度:-40~+80℃
E100-7M-420-x-A
E100-7M-420-x-A, UL certified, suitable for TT/TN system protection, up to 100KA 8/20
MV80P-320-R
MV80P-320-R
DN-05/RS485-3G
DN-05/RS485-3G
DN-xxx-MB/G2
JDA DN-xxx-MB/G2 data network arrester applied in protection for 2 single wires of balanced interfaces with measuring and controlling system, providing coarse and fine protection, suitable for use in category location B, C (ANSI/IEEE C62.41) or directly at the upstream near the protected devices. Technical Features ◎ Data network protector in according with UL497b,IEC61643-21:2012; ◎ Compact size of 6.2mm to safe much installation space ◎ 35mm Din-rail mounting design; ◎ Limit the transients with gas discharge tubes and transzorb diodes; ◎ Three-stage protection circuit. ◎ Universal one pair data/communication lines protection
DN-xxx-MB/G4
JDA DN-xxx-MB/G4 MODBUS RS485 Data network arrester provide protection for four single lines or two-pair lines in the high-frequency bus systems or video transmissions, suitable for use in category location B, C (ANSI/IEEE C62.41) or directly at the upstream near the protected devices. Technical Features ◎ Data network protector in according with UL497b, IEC61643-:21:2012; ◎ Compact size of 7 mm to safe much installation space ◎ 35mm Din-rail mounting design; ◎ Limit the transients with gas discharge tubes and transzorb diodes; ◎ Two-stage protection circuit. ◎ 4-lines or twp-pair lines protection
DN-24/BNC-50
DN-24/BNC-XX surge arrester is designed for coaxial systems protection against the damaging from surges and spikes caused by lightning and other electrical sources, suitable for use in category location B, C (ANSI/IEEE C62.41) or directly at the upstream near the protected devices. Technical Features ◎Data network protector in according with UL497b,IEC61643-21:2012; ◎High discharge capability, total nominal discharge current up to 20kA 8/20; ◎Two-stage protection circuit; ◎Limit the transient with gas discharge tubes and transzorb diodes; ◎Low insertion loss;
DN-24/BNC-75
JDA DN-24/BNC-75 surge arrester is designed for coaxial systems protection against the damaging from surges and spikes caused by lightning and other electrical sources, suitable for use in category location B, C (ANSI/IEEE C62.41) or directly at the upstream near the protected devices. Technical Features ◎ Data network protector in according with UL497b,IEC61643-21:2012; ◎ High discharge capability, total nominal discharge current up to 20kA 8/20; ◎ Two-stage protection circuit; ◎ Limit the transient with gas discharge tubes and transzorb diodes; ◎ Low insertion loss;
DN-24-RS485-BG
RS485 ModBus surge protector
DN24-RS485
コンビネーションウェーブ: 8/20us, 10/20KA, 環境温度-40~+70℃
DN-48/RJ45-CAT6-HS(POE)
This Cat6-PoE Protector is designed for protecting Gigabit Ethernet terminals such as Internet camera, IP Telephone sets, and wireless access point, suitable for use in category location B, C (ANSI/IEEE C62.41) or directly at the upstream near the protected devices. Technical Features ◎ Data network protector In according with standard IEEE802.3at/af,UL497b,IEC61643-21 ◎ PoE compatible, Ethernet CAT6 system protection ◎ High discharge capability, total nominal discharge current 10kA 8/20 and Lightning current up to 1.0KA ◎ In aluminum housing ◎ RJ45 connector for cat6 network technology, 100BaseT, 1000BaseT/1000BaseTx, 8 wires protection
DRF25-175-25A-3MV-C(-R)
Surge protective device especially for low-voltage power supply system surge protection at the boundaries from lightning protection zone 2-3 and higher. ◎ Multi-stage protection circuit with LC Filter design to protect sensitive electronics. ◎ Provides extensive high frequency & RF filtering ◎ Application for 120~127Vac,220~277Vac(L-N) TT, TN or any 1-phase system with a grounded neutral ◎ Protection capability 25kA 8/20 us ◎ Built in backup fuse for fault current protection ◎ All mode protection ◎ LED failure indication ◎ Remote alarm function available
LED照明専用サージ保護デバイス RL2MV+G-320-10-X
サージ保護デバイス(或いは吸收デバイス) サージ耐量8/20us In/Imax 10/20KA, 難燃性UL94-V0,, 温度:-40~+70℃ XX : Imax KA ; YYY : max Uc
Surge Protector (Square)
Surge Protector (Square)
Surge Protector (Round)
Surge Protector (Round)
Surge Protector (Round Pin)
Surge Protector (Round Pin)
雷サージ計数器 ECL-A-24
センサー:>100A、LEDランプ表示、ホール素子。 据え付け:DIN rail、インジケーター:0~99、 電池寿命:1年、電池:7.2V、充電式電池、 寸法:DIN43880, 2module、広さ:36mm、難燃性UL94-V0,, 温度:-40~+80℃
雷サージ計数器 ECL-A-9
センサー:>100A、LEDランプ表示、ホール素子。 据え付け:DIN rail、インジケーター:0~99、 電池寿命:1年、電池:7.2V、充電式電池、 寸法:DIN43880, 2module、広さ:36mm、 難燃性UL94-V0,, 温度:-20~+60℃
交流サージ吸收デバイスESF50-1/xxx- 32A-3P
コード説明 タイプ:ESF&&-x/***-##A-$$ ESF: 囲い式サージパワーフィルター &&:最大サージ電流(25KA ~200KA可能) X:1/3:電力システム(単相、3相) ***:入力電圧:Uc(180/320/420/550) ##:定格電流-連続(5A/10A/16A/20A/32A/50A/63A/100A/ 120A… ) $$:3P/PN/3PN 保護モード:(L-N,L-PE,N-PE 3MOV/L-N,N-PE 1MOV+1GDT/L-N,N-PE 3MOV+1GDT) アプリケーション:第2電源回路、サブボード、コンピューター システム 、医療システム、通信システム、精留器、全て感度の高い設備、 プロセスと制御システム
LED街灯用サージ保護デバイス
LED街灯用サージ保護デバイス
JDA信号サージ保護デバイス DN-05RS485-2G-B
信号サージ保護デバイス DN-&&/xxxxx-2G-B xxxxx:RS232, RS422,RS423,RS485,0/4-20mA,0-5V,0-10V A タイプ:配電盤の内でメータ24V 0/4~20mA S232,RS422 ,RS423,RS485,0-5V,0-10V、信号使用、据え付け:DIN rail B タイプ:サージ耐量8/20us 容量:10KA In,20KA Im。 C タイプ:電圧制限(サージ保護)Cat.B(@3KA)、 テスト条件≦75V, 8/20us impulse-5KA 35V。
JDA信号サージ保護デバイス DN-&&/xxxxx-2G
信号サージ保護デバイス DN-&&/xxxxx-2G xxxxx:RS232 ,RS422,RS423,RS485,0/4-20mA,0-5V,0-10V A タイプ:配電盤の内でメータ24V 0/4~20mA S232,RS422 ,RS423,RS485,0-5V,0-10V、信号使用、据え付け:DIN rail B タイプ:サージ耐量8/20us 容量:10KA In,20KA Im。 C タイプ:電圧制限(サージ保護)Cat.B(@3KA)、 テスト条件≦75V, 8/20us impulse-5KA35V。
JDA信号サージ保護デバイス DN-&&/xxxxx/G
プラグ挿入式、据え付け:DIN レール サージ耐量8/20us In/Imax 5/10KA, 温度:-40~+70℃
電源雷サージ器 SDT-110-20-F1
1, 2ポートF型サージ保護デバイス 2、 IEC61643-11.ANSI/IEEE C62.41-1991標準デザインより、 3、 110V単相システム保護 4、 35mm据え付け:DIN レール 5、 LED燈故障指示 6、 電圧制限(サージ保護): 110V時に,≦[800]V。 7、 負荷電流=5A
信号サージ保護デバイス SSP-24
1. サージ保護デバイス, 2. 雷保護領域LPZ0B—2対応或いは他の領域 3低電圧保護レベル 4 直流電力供給の電源保護 5. 35mm据え付け:DIN レール 6. 電圧制限(サージ保護): Cat.B(@3KA)、テスト条件≦75V 7. IEC61643-21.ANSI/IEEE C62.41-1991標準認証と取得済み
RJ45 サージ保護デバイス
RJ45 サージ保護デバイス
RJ45 サージ保護デバイス ITB-05-RJ45H-24P
RJ45 サージ保護デバイス
JDA PVサージ吸收/保護デバイス MTMV-xxx
